Atop Industrial Serial Device Server
SE5408A/SE5416A Series
User Manual V 1.0
12
3 Getting Started
3.1 Model Comparison
Model
Description
SE5408A
8-Port Industrial Serial Device Server, RS-232, AC Inlet, US Plug, Rack Mount
SE5408A-DC
8-Port Industrial Serial Device Server, RS-232, DC TB3, Rack Mount
SE5408A-S5
8-Port Industrial Serial Device Server, RS-422/485, AC Inlet, US Plug, Rack Mount
SE5408A-S5-DC
8-Port Industrial Serial Device Server, RS-422/485, DC TB3, Rack Mount
SE5408A-EU
8-Port Industrial Serial Device Server, RS-232, AC Inlet, EU Plug, Rack Mount
SE5408A-EU-S5
8-Port Industrial Serial Device Server, RS-422/485, AC Inlet, EU Plug, Rack Mount
SE5416A
16-Port Industrial Serial Device Server, RS-232, AC Inlet, US Plug, Rack Mount
SE5416A-DC
16-Port Industrial Serial Device Server, RS-232, DC TB3, Rack Mount
SE5416A-S5
16-Port Industrial Serial Device Server, RS-422/485, AC Inlet, US Plug, Rack Mount
SE5416A-S5-DC
16-Port Industrial Serial Device Server, RS-422/485, DC TB3, Rack Mount
SE5416A-EU
16-Port Industrial Serial Device Server, RS-232, AC Inlet, EU Plug, Rack Mount
SE5416A-EU-S5
16-Port Industrial Serial Device Server, RS-422/485, AC Inlet, EU Plug, Rack Mount
