Specifications

39
8.2 PAINT FILTER SET
For MSU 113 N : model with filter
Pos. Description Quantity
A Paint filter set 1
1 Plug 1
2 Cylinder 1
3 Filter plug 1
4 Filter bolt 1
5 100 mesh filter 1
6 Packing 1
7 Nut 1
8 Packing 1
9 Union joint R3/8”-G3/8” 1
10 Pin 1
11 Filter adaptor 1
12 Elbow Rp3/8” FF 1
13 Joint R3/8”-G1/4” 1
14 Elbow R1/4”MM 1
15 Two-way valve G1/4”FF 1
16 Hose joint R1/4” M8x6 1
17 Body 1
8.3 DRAIN VALVE SET
For MSU 113 N: model without paint filter
Pos. Descrizione Quantity
A Drain valve set 1
1 Elbow MM R3/8”-G1/4” 1
2 T Joint Rp 3/8”FFF 1
3 Nipple R3/8”M – R1/4”M 1
4 Two-way ball valve G1/4” FF 1
5 Hose joint R1/4”M M8x6 1
6 Union joint R3/8”M-G3/8”F 1
A
A
