Specifications

11
2.3 Technical specifications
Model MSU-113N MSU-113N
Model Model with filter Model without filter
(Figure 1) (Figure 2)
Dimensions mm 524x500x1020 524x500x1020
Weight kg 18 Kg 16.5 Kg
Pump type PP-7131N (Model in stainless steel)
Compression ratio 13:1
Inlet air pipe fitting G1/4”
Outlet air pipe fitting G1/4”
Material inlet pipe fitting G1/2”
Material outlet pipe fitting G1/4”
Maximum working pressure 6.8 bar
Max fluid pressure 88 bar
Max. fluid delivery 1.9L/min
Max numer of cycle per min 110 cycle/min
Delivery/cycle 17.3cc/cycle
Fluid suction filter 50 mesh
Working temperature 5 - 40°C
Noise level 81.6dB(A)
Compressor (required power) 0.37-1.5Kw
FIGURE 1 FIGURE 2
