XMEGA E5 [DATASHEET]

Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014

36.13 Clock and Oscillator Characteristics

36.13.1 Calibrated 32.768kHz Internal Oscillator Characteristics

Table 36-20. 32.768kHz Internal Oscillator Characteristics

36.13.2 Calibrated 8MHz Internal Oscillator Characteristics

Table 36-21. 8MHz Internal Oscillator Characteristics

36.13.3 Calibrated and Tunable 32MHz Internal Oscillator Characteristics

Table 36-22. 32MHz Internal Oscillator Characteristics

36.13.4 32 kHz Internal ULP Oscillator Characteristics

Table 36-23. 32 kHz Internal ULP Oscillator Characteristics

Symbol Parameter Condition Min. Typ. Max. Units

Frequency 32.768 kHz

Factory calibration accuracy T = 25°C, V

= 3.0V -0.5 0.5

User calibration accuracy -0.5 0.5

Symbol Parameter Condition Min. Typ. Max. Units

Frequency range 4.4 9.4

MHz

Factory calibrated frequency 8

Factory calibration accuracy T = 25°C, V

= 3.0V -0.5 0.5

User calibration accuracy -0.5 0.5

Symbol Parameter Condition Min. Typ. Max. Units

Frequency range

DFLL can tune to this frequency over voltage

and temperature

30 55

MHz

Factory calibrated frequency 32

Factory calibration accuracy T = 25°C, V

= 3.0V -1.5 1.5

%User calibration accuracy -0.2 0.2

DFLL calibration step size 0.23

Symbol Parameter Condition Min. Typ. Max. Units

Output frequency 32 kHz

Accuracy -30 30 %
