83
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Table 36-19. Programming Time
Notes: 1. Programming is timed from the 2MHz output of 8MHz internal oscillator.
2. EEPROM is not erased if the EESAVE fuse is programmed.
Parameter Condition Min. Typ.
(1)
Max. Units
Chip Erase
32KB Flash, EEPROM
(2)
50
ms
16KB Flash, EEPROM
(2)
45
8KB Flash, EEPROM
(2)
42
Flash
Page erase 4
Page write 4
Atomic page erase and write 8
EEPROM
Page erase 4
Page write 4
Atomic page erase and write 8
