Table 36-4. Current Consumption for Modules and Peripherals
Notes: 1. All parameters measured as the difference in current consumption between module enabled and disabled. All data at V
CC
= 3.0V, Clk
SYS
= 1MHz external clock
without prescaling, T = 25°C unless other conditions are given.
Symbol Parameter Condition
(1)
Min. Typ. Max. Units
I
CC
Internal ULP oscillator 100 nA
32.768kHz int. oscillator 27
µA
8MHz int. oscillator
Normal power mode 65
Low power mode 45
32MHz int. oscillator
275
DFLL enabled with 32.768kHz int. osc. as reference 400
PLL
20x multiplication factor,
32MHz int. osc. DIV4 as reference
230
Watchdog timer 0.3
BOD
Continuous mode 245
Sampled mode 0.4
Internal 1.0V reference 200
Internal temperature sensor 100
ADC
16ksps
V
REF
= Ext. ref.
1.5
mA
CURRLIMIT = LOW 1.4
CURRLIMIT = MEDIUM 1.3
CURRLIMIT = HIGH 1.2
75ksps, V
REF
= Ext. ref. CURRLIMIT = LOW 1.7
300ksps, V
REF
= Ext. ref. 3.1
DAC
250ksps
V
REF
= Ext. ref.
No load
Normal mode 1.9
Low Power mode 1.1
AC 200
µA
EDMA 200
Timer/counter 25
USART Rx and Tx enabled, 9600 BAUD 8
XCL 16-bit timer/counter 6
Flash memory and EEPROM programming 4 mA
