66
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
SPM Z+ Store Program Memory and Post-Increment by 2
(RAMPZ:Z)
Z
R1:R0,
Z + 2
None -
IN Rd, A In From I/O Location Rd
I/O(A) None 1
OUT A, Rr Out To I/O Location I/O(A)
Rr None 1
PUSH Rr Push Register on Stack STACK
Rr None 1
(1)
POP Rd Pop Register from Stack Rd
STACK None 2
(1)
XCH Z, Rd Exchange RAM location
Tem p
Rd
(Z)
Rd,
(Z),
Tem p
None 2
LAS Z, Rd Load and Set RAM location
Tem p
Rd
(Z)
Rd,
(Z),
Temp v (Z)
None 2
LAC Z, Rd Load and Clear RAM location
Tem p
Rd
(Z)
Rd,
(Z),
($FFh – Rd)
(Z)
None 2
LAT Z, Rd Load and Toggle RAM location
Tem p
Rd
(Z)
Rd,
(Z),
Tem p (Z)
None 2
Bit and bit-test instructions
LSL Rd Logical Shift Left
Rd(n+1)
Rd(0)
C
Rd(n),
0,
Rd(7)
Z,C,N,V,H 1
LSR Rd Logical Shift Right
Rd(n)
Rd(7)
C
Rd(n+1),
0,
Rd(0)
Z,C,N,V 1
ROL Rd Rotate Left Through Carry
Rd(0)
Rd(n+1)
C
C,
Rd(n),
Rd(7)
Z,C,N,V,H 1
ROR Rd Rotate Right Through Carry
Rd(7)
Rd(n)
C
C,
Rd(n+1),
Rd(0)
Z,C,N,V 1
ASR Rd Arithmetic Shift Right Rd(n)
Rd(n+1), n=0..6 Z,C,N,V 1
SWAP Rd Swap Nibbles Rd(3..0)
Rd(7..4) None 1
BSET s Flag Set SREG(s)
1 SREG(s) 1
BCLR s Flag Clear SREG(s)
0 SREG(s) 1
SBI A, b Set Bit in I/O Register I/O(A, b)
1 None 1
CBI A, b Clear Bit in I/O Register I/O(A, b)
0 None 1
BST Rr, b Bit Store from Register to T T
Rr(b) T 1
BLD Rd, b Bit load from T to Register Rd(b)
T None 1
SEC Set Carry C
1 C 1
CLC Clear Carry C
0 C 1
SEN Set Negative Flag N
1 N 1
CLN Clear Negative Flag N
0 N 1
SEZ Set Zero Flag Z
1 Z 1
CLZ Clear Zero Flag Z
0 Z 1
SEI Global Interrupt Enable I
1 I 1
Mnemonics Operands Description Operation Flags #Clocks
