LDS Rd, k Load Direct from data space Rd
(k) None 2
(1)(2)
LD Rd, X Load Indirect Rd
(X) None 1
(1)(2)
LD Rd, X+ Load Indirect and Post-Increment
Rd
X
(X)
X + 1
None 1
(1)(2)
LD Rd, -X Load Indirect and Pre-Decrement
X X - 1,
Rd (X)
X - 1
(X)
None 2
(1)(2)
LD Rd, Y Load Indirect Rd (Y)
(Y) None 1
(1)(2)
LD Rd, Y+ Load Indirect and Post-Increment
Rd
Y
(Y)
Y + 1
None 1
(1)(2)
LD Rd, -Y Load Indirect and Pre-Decrement
Y
Rd
Y - 1
(Y)
None 2
(1)(2)
LDD Rd, Y+q Load Indirect with Displacement Rd
(Y + q) None 2
(1)(2)
LD Rd, Z Load Indirect Rd
(Z) None 1
(1)(2)
LD Rd, Z+ Load Indirect and Post-Increment
Rd
Z
(Z),
Z+1
None 1
(1)(2)
LD Rd, -Z Load Indirect and Pre-Decrement
Z
Rd
Z - 1,
(Z)
None 2
(1)(2)
LDD Rd, Z+q Load Indirect with Displacement Rd
(Z + q) None 2
(1)(2)
STS k, Rr Store Direct to Data Space (k)
Rd None 2
(1)
ST X, Rr Store Indirect (X)
Rr None 1
(1)
ST X+, Rr Store Indirect and Post-Increment
(X)
X
Rr,
X + 1
None 1
(1)
ST -X, Rr Store Indirect and Pre-Decrement
X
(X)
X - 1,
Rr
None 2
(1)
ST Y, R r Store Indirect (Y)
Rr None 1
(1)
ST Y+, Rr Store Indirect and Post-Increment
(Y)
Y
Rr,
Y + 1
None 1
(1)
ST -Y, Rr Store Indirect and Pre-Decrement
Y
(Y)
Y - 1,
Rr
None 2
(1)
STD Y+q, Rr Store Indirect with Displacement (Y + q)
Rr None 2
(1)
ST Z, Rr Store Indirect (Z)
Rr None 1
(1)
ST Z+, Rr Store Indirect and Post-Increment
(Z)
Z
Rr
Z + 1
None 1
(1)
ST -Z, Rr Store Indirect and Pre-Decrement Z
Z - 1 None 2
(1)
STD Z+q,Rr Store Indirect with Displacement (Z + q)
Rr None 2
(1)
LPM Load Program Memory R0
(Z) None 3
LPM Rd, Z Load Program Memory Rd
(Z) None 3
LPM Rd, Z+ Load Program Memory and Post-Increment
Rd
Z
(Z),
Z + 1
None 3
ELPM Extended Load Program Memory R0
(RAMPZ:Z) None 3
ELPM Rd, Z Extended Load Program Memory Rd
(RAMPZ:Z) None 3
ELPM Rd, Z+
Extended Load Program Memory and Post-
Increment
Rd
Z
(RAMPZ:Z),
Z + 1
None 3
SPM Store Program Memory (RAMPZ:Z)
R1:R0 None -
Mnemonics Operands Description Operation Flags #Clocks
