0x07E0 PORTR Port R
0x0800 TCC4 Timer/Counter 4 on port C
0x0840 TCC5 Timer/Counter 5 on port C
0x0880 FAULTC4 Fault Extension on TCC4
0x0890 FAULTC5 Fault Extensionon TCC5
0x08A0 WEXC Waveform Extension on port C
0x08B0 HIRESC High Resolution Extension on port C
0x08C0 USARTC0 USART 0 on port C
0x08E0 SPIC Serial Peripheral Interface on port C
0x08F8 IRCOM Infrared Communication Module
0x0940 TCD5 Timer/Counter 5 on port D
0x09C0 USARTD0 USART 0 on port D
Base Address Name Description
