32. Pinout and Pin Functions
The device pinout is shown in “Pinout and Block Diagram” on page 4. In addition to general purpose I/O functionality,
each pin can have several alternate functions. This will depend on which peripheral is enabled and connected to the
actual pin. Only one of the pin functions can be used at time.
32.1 Alternate Pin Function Description
The tables below show the notation for all pin functions available and describe its function.
32.1.1 Operation/Power Supply
32.1.2 Port Interrupt Functions
32.1.3 Analog Functions
32.1.4 Timer/Counter and WEX Functions
32.1.5 Communication Functions
V
CC
Digital supply voltage
AV
CC
Analog supply voltage
GND Ground
SYNC Port pin with full synchronous and limited asynchronous interrupt function
ASYNC Port pin with full synchronous and full asynchronous interrupt function
ACn Analog Comparator input pin n
ACnOUT Analog Comparator n Output
ADCn Analog to Digital Converter input pin n
DACn Digital to Analog Converter output pin n
A
REF
Analog Reference input pin
OCnx Output Compare Channel x for timer/counter n
OCnxLS Output Compare Channel x Low Side for Timer/Counter n
OCnxHS Output Compare Channel x High Side for Timer/Counter n
SCL Serial Clock for TWI
SDA Serial Data for TWI
SCLIN Serial Clock In for TWI when external driver interface is enabled
SCLOUT Serial Clock Out for TWI when external driver interface is enabled
SDAIN Serial Data In for TWI when external driver interface is enabled
SDAOUT Serial Data Out for TWI when external driver interface is enabled
