32
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
16.3.4 Bus-keeper
The bus-keeper’s weak output produces the same logical level as the last output level. It acts as a pull-up if the last level
was ‘1’, and pull-down if the last level was ‘0’.
Figure 16-4. I/O Configuration - Totem-pole with Bus-keeper
16.3.5 Others
Figure 16-5. Output Configuration - Wired-OR with Optional Pull-down
Figure 16-6. I/O Configuration - Wired-AND with Optional Pull-up
INxn
OUTxn
DIRxn
Pxn
INxn
OUTxn
Pxn
INxn
OUTxn
Pxn
