142
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
39.7 8153D – 06/2013
39.8 8153C – 05/2013
39.9 8153B – 04/2013
39.10 8153A – 04/2013
1. Analog Comparator Characteristics: Updated minimum and maximum values of Input Voltage Range, Table 36-14
on page 80.
1. Electrical Characteristics, Table on page 73: Updated typical value from 7mA to 6mA for Active Current
Consumption, 32MHz, V
CC
=3.0V.
2. Errata “Rev. A” and “Rev. B” : Added DAC errata: AREF on PORT C0.
1. “Rev. B” on page 136: Removed the “EDMA: Channel transfer never stops when double buffering is enabled on
sub-sequent channels” errata.
1. Initial revision.
