XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-82. 32MHz internal Oscillator Frequency vs. CALB Calibration Value
V
CC
= 3.0V
37.11 Two-wire Interface Characteristics
Figure 37-83. SDA Fall Time vs. Temperature
Frequency [MHz]
20.00
30.00
40.00
50.00
60.00
70.00
0 8 16 24 32 40 48 56 64
CALB
Temperature -40
25
85
105
Temperature [°C]
-40 -20 0 20 40 60 80 100 120
Fall Time [ns]
10
20
30
40
50
60
70
80
Mode
FAST
FAST +
STD
