XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-65.Reset Pin Pull-up Resistor Current vs. Reset Pin Voltage
V
CC
= 3.3V
Figure 37-66.Reset Pin Input Threshold Voltage vs. V
CC
V
IH
- Reset pin read as “1”
IRESET [uA]
-150
-125
-100
-75
-50
-25
0
0.0 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0 3.3
VRESET [V]
Tem perature -40
25
85
105
,
V_threshold_ [V]
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Vcc [V]
T [°C] -40
25
85
105
