123
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-61.BOD Thresholds vs. Temperature
BOD level = 3.0V
37.8 External Reset Characteristics
Figure 37-62.Minimum Reset Pin Pulse Width vs. V
CC
VBOT [V]
2.95
3.00
3.05
3.10
-30 -15 0 15 30 45 60 75 90 105
Temperature [°C]
Test Info fall
rise
t_RST_ [ns]
80
90
100
110
120
130
140
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Vcc [V]
T [°C] -40
25
85
105
