115
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-45. ADC Offset Error vs. V
REF
T = 25
C, V
CC
= 3.6V, ADC sample rate = 300ksps
Figure 37-46.ADC Gain Error vs. Temperature
V
CC
= 3.6V, V
REF
= external 1.0V, sample rate = 300ksps
Offset [mV]
5.0
10.0
15.0
20.0
25.0
30.0
1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
Vref [V]
Mode
Differential mode
Single-ended signed mode
Single-ended unsigned mode
Gain error [mV]
-7.0
-6.0
-5.0
-4.0
-3.0
-2.0
-1.0
0.0
-40 -20 0 20 40 60 80 100
Temperature [°C]
Mode
Differential mode
Single-ended signed mode
Single-ended unsigned mode
