113
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-41. ADC Gain Error vs. V
CC
T = 25
C, V
REF
= 1.0V, ADC sample rate = 300ksps
Figure 37-42. ADC Gain Error vs. V
REF
T = 25
C, V
CC
= 3.6V, ADC sample rate = 300ksps
Gain error [mV]
-5.0
-4.0
-3.0
-2.0
-1.0
0.0
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Vcc [V]
Mode
Differential mode
Single-ended signed mode
Single-ended unsigned mode
Gain error [mV]
-14.0
-12.0
-10.0
-8.0
-6.0
-4.0
-2.0
0.0
1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0
Vref [V]
Mode
Differential mode
Single-ended signed mode
Single-ended unsigned mode
