108
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-31.I/O Pin Output Voltage vs. Sink Current
V
CC
= 3.0V
Figure 37-32.I/O Pin Output Voltage vs. Sink Current
V
CC
= 3.3V
VPIN [V]
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0 2 4 6 8 10 12 14 16 18 20
IPIN [mA]
Temperature 25
85
105
-40
VPIN [V]
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0 2 4 6 8 10 12 14 16 18 20
IPIN [mA]
Temperature 25
85
105
-40
