106
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
Figure 37-27.I/O Pin Output Voltage vs. Source Current
V
CC
= 3.0V
Figure 37-28.I/O Pin Output Voltage vs. Source Current
V
CC
= 3.3V
VPIN [V]
2.3
2.4
2.5
2.6
2.7
2.8
2.9
3.0
-10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0
IPIN [mA]
Temperature 25
85
105
-40
VPIN [V]
2.6
2.7
2.8
2.9
3.0
3.1
3.2
3.3
-10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0
IPIN [mA]
Temperature 25
85
105
-40
