XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
37.2 I/O Pin Characteristics
37.2.1 Pull-up
Figure 37-23.I/O pin pull-up Resistor Current vs. Input Voltage
V
CC
= 1.8V
Figure 37-24.I/O Pin Pull-up Resistor Current vs. Input Voltage
V
CC
= 3.0V
IPIN [uA]
-70
-60
-50
-40
-30
-20
-10
0
10
0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8
VPIN [V]
Tem perature -40
25
85
105
IPIN [uA]
-120
-100
-80
-60
-40
-20
0
20
0.0 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.0
VPIN [V]
Tem perature -40
25
85
105
