103
XMEGA E5 [DATASHEET]
Atmel-8153J–AVR-ATxmega8E5-ATxmega16E5-ATxmega32E5_Datasheet–11/2014
37.1.5 Standby Mode Supply Current
Figure 37-21.Standby Supply Current vs. V
CC
Standby, f
SYS
=1MHz
Figure 37-22.Standby Supply Current vs. V
CC
25°C, running from different crystal oscillators
ICC [uA]
1
2
3
4
5
6
7
8
9
10
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Vcc [V]
Tem perature -40
25
85
105
Vcc [V]
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Idd [µA]
150
200
250
300
350
400
450
500
Crystals
0.455MHz
12.0MHz
16.0MHz
2.0MHz
8.0MHz
