Figure 37-15.Idle Mode Supply Current vs. V
CC
f
SYS
= 32MHz internal oscillator prescaled to 8MHz
Figure 37-16.Idle Mode Supply Current vs. V
CC
f
SYS
= 32MHz internal oscillator
ICC [mA]
0.6
0.8
1.0
1.2
1.4
1.6
1.8
1.6 1.8 2.0 2.2 2.4 2.6 2.8 3.0 3.2 3.4 3.6
Vcc [V]
Temperature -40
25
85
105
ICC [mA]
2.5
3.0
3.5
4.0
4.5
2.6 2.7 2.8 2.9 3.0 3.1 3.2 3.3 3.4 3.5 3.6
Vcc [V]
Temperature -40
25
85
105
