Incoming air
temperature
Air temperature sensor in the flow of ambient air
Evaporator
temperature
Temperature sensor on a cross in the evaporator
Water temperature Water temperature sensor in the pocket
Heat pump time Shows the working time of the water heater heat pump in hours
Elec time Shows the working time of the water heater electric backup in hours
Description of the modes
Graphical icons Description Indicator
Optimised management of the heat pump and the
electrics for guaranteed comfort
Heat pump only working
Forced operation with electrics + heat pump when
heating
Long absence: water heating set to anti-freezing
mode and restart on the last day of absence
Indication of the various sensor temperatures and the
operating time of the heat pump or the electric
backup
This mode is selected
when the cursor is
positioned above the icon.
AUTO mode
This mode automatically selects the energy source for maximum savings, while guaranteeing that the
water is sufficiently hot.
The water heater always selects the heat pump first. If the air temperatures are not in the operating range,
or if a fault is detected in the heat pump, the electric backup is automatically selected to guarantee a
sufficient volume of hot water.
Examples:
Severe winters
Use of 3/4 of the available volume
of hot water
Air temperature about 1°C
Winter
Use of 3/4 of the available volume
of hot water
Air temperature about 7°C
Summer
Use of 2/3 of the available volume
of hot water Air temperature about
18°C
Selection by the regulation:
Heat pump plus electric backup
Selection by the regulation:
Heat pump only, with authorisation
to continue even in case time clock
signal is off (“HP” on the screen)
Selection by the regulation:
Heat pump only and only when
time clock signal is on
(“HC” on the screen)
