powered subwoofer Instruction Manual 172 PBM

12
Model 172 PBM
The lightning flash with arrowhead, within an
equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a
risk of electrical shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating maintenance
(servicing) instructions in the literature
accompanying the appliance.
Model 172 PBM Specifications
CAUTION: To reduce the risk of electric shock, do not remove
the cover (or back). No user serviceable parts inside. Refer to
qualified personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
For Future Reference
Record your speaker serial number and date of purchase here:
Model Number Serial Number Date of Purchase
The serial number is found on the back of the speaker near the connecting terminals.
Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. Dolby Digital, AC-3,
Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation. DTS is a registered trademark of DTS Technology.
010-1172
Type/Features Powered Subwoofer with Sealed Acoustic-Suspension Enclosure
Variable 50-150 Hz, 12 dB/Octave low pass output
Fixed 24 dB/Octave 180 Hz Low-Pass Filter
Dual Diversity Crossover System (DDC)™
Driver (1) 12" long-throw woofer, 2”, 4 layer vented aluminum voice coil, vented
motor system
Amplifier Power 150 Watts RMS all discrete linear Class G power amplifier with dual
power supplies
Amplifier Distortion <0.025%
Frequency Response 20-180 Hz ±3dB
Peak output (SPL) 108dB
Dimensions 13.8in x 19.7in x 13.8in; 350mm x 500mm x 350mm
Weight 42.75lbs.; 19.4kg.
