Specifications

6 / 10
7. Electrical Specification
7.1. IEEE802.15.4
The REBE-TZ15K supports IEEE802.15.4.
7.2. General Specification
• Standard : Only IEEE802.15.4 PHY
• Frequency : 2405 ~ 2480MHz
• Channel : 16CH. (5MHz Spacing)
• Modulation : DSSS/O-QPSK
• Max. Data Rate : 250Kbps
7.3. Electrical Specification
• Channel power depend on each country regulations (EX. KC, etc)
• The electrical specification which is shown below is ATEC IOT internal specification.
• All values depend on surrounding environment and current statement of access point
RF Performance
Parameter
Condition
Min Typ Max Unit
Output Power -
0 - - dBm
Receiver Sensitivity
PER=1% (Required -85dBm) -85 - - dBm
Maximum Input Level
PER=1% (Required -20dBm)
- - -20
dBm
Frequency Tolerance
Required Max.
±
75kHz -75 - 75 ppm
Error Vector Magnitude
Required Max. 35% - - 35 %
