Specifications

4 / 10
5. General Features
5.1. Description
Item Description
Size
93.5(H)X 44(V) X 13(L)
Operating
Environment
-. CPU : Cortex-A9 (1GHz)
-. Memory : eMMC 16GB, DDR3 SDRAM 2GB
-. 3 RF ZIGBEE Module
-. Host USB2.0 Port supported for WiFi AP
-. OS : Linux Kernel 4.1.15
-. Network & maintenance function
▷ Network setup / management
▷ Software upgrade
-. On ceiling using bracket
Power
Rate : 5.0 V / 600 mA
Network
802.15.4 2.4GHz IEEE802.15.4 compliant RF Transceiver
Security Robust wireless network (ATEC IOT own protocol)
Protocol Compatible with ATEC IOT protocol communication devices
Comm. Range Max. 30m (Under LoS)
(3)(4)
[Notice] (1) Communication Range depends on surrounding environment
(2) Use the enclosed product for the antenna and do not use any other product..
