Specifications

Use ALIAS numbers, if
optioned. Otherwise, use
Physical zone/group numbers.
Door Service
NOTE: If a Connect password
has been installed in your
system, you will have to
access the paging system and
enter your password, before
being automatically routed to
the zone.
If the doorbell input has a
higher priority than the
telephone access and is
activated while telephone
access paging is underway,
then you will receive the tone
specified in the option “Tone
Selection,” above, and then
will be automatically routed to
the proper zone.
1.
2.
3.
4.
Dial 9 6 to select Audio Source Enable.
Hear a DOUBLE beep.
Enter the input zone or group number.
Hear a DOUBLE beep.
Enter 0 (NONE), 1 (AA, Attendant Access), or 2 (T/R, Telephone
Access) to select the audio source (or none) to be enabled when
this zone is activated.
Hear TRIPLE beeps.
To verify your selection, Dial 9 7 and repeat steps 2 and 3, above.
30
Set Audio Routing
If optioned, whenever a selected input zone with “Audio Source Enabled”
is active, the audio source (either Telephone Access or Attendant
Access) will be routed to the selected zone or group. The default for this
parameter is NO ZONES.
The primary use for this feature is to allow the paging system to be used
for door service. For example, you have optioned the doorbell input
zone to enable Telephone Access, and you wish now to select the door
speaker to be the output zone for this Telephone Access audio.
The audio path will remain routed for 10 seconds. If the user accesses
the controller during the 10 second period, they will automatically be
routed to the zone specified in this procedure. If the user accesses the
controller after the time expires, the user will receive a dial tone.
1.
2.
3.
4.
Dial 9 8 to select Audio Routing.
Hear DOUBLE beeps.
Enter the input zone or group zone number.
Hear DOUBLE beeps.
Enter the output zone / group ALlAS number.
Hear TRIPLE beeps.
To verify your selection, dial 9 9 and repeat steps 2 and 3 above.
