22
Set Page Enable
NOTE: If you make an all-call
page and this option is
selected NO in either a Zone
Group or Individual Zones,
then an all-call page will be
made to all other zones except
the ones specified. If the
decision is NO for the All-Call
zone and an all-call page is
made, then an error tone will
be returned to you.
NOTE: Use ALIAS numbers, if
optioned. Otherwise, use
Physical zone/group numbers.
NOTE: Use ALIAS numbers, if
optioned. Otherwise, use
Physical zone/group numbers.
NOTE: Refer to the
Applications notes on
Talkback, page 62.
This output zone parameter enables paging for a selected output zone or
zone group. The choice for this selection is YES/NO, with the default
being YES. Repeat this procedure for each output zone or zone group.
1.
2.
3.
4.
Dial
7 4
to select this option.
Hear a DOUBLE beep.
Enter the zone number, of the zone or group you wish to configure.
Hear a DOUBLE beep.
Enter
0
for NO (Page Not Enabled) or
1
for YES (Page enabled)
Hear TRIPLE beeps.
To verify the status of Page Enable for a given zone, dial
7 3
and
repeat steps 2 and 3 above.
23
Set Music Enable if Background Music is Used
This is an individual zone output parameter, that enables background
music to be broadcast to a selected output zone (in the absence of a
higher priority paging output). The choice is YES/NO, with the default
being NO. Repeat this procedure for each output zone that you wish to
have background music.
1.
2.
3.
4.
Dial
7 4
to select this option.
Hear a DOUBLE beep.
Enter the zone or group zone number.
Hear a DOUBLE beep.
Enter
0
for NO (Music Not Enabled) or
1
for YES (Music enabled)
Hear TRIPLE beeps.
To verify the status of Music Enable for a given zone, dial
7 5
and repeat steps 2 and 3 above.
24
Set Talkback Enable
This is a zone output parameter that enables talkback capability for a
selected output zone or group. The choice is YES/NO, with the default
being set to NO.
All speakers in a zone or group will be active 2-way speakers if talkback
has been enabled for a zone. Repeat this procedure for each output
zone or zone group that you wish to have talk-back.
