Specifications

For example, dial 81 for zone
group 81 (Zone group 80 is
always All Call). Use ALIAS
numbers, if optioned.
Otherwise, use Physical
zone/group numbers.
For example, 01 (tone), 02
(tone), 13 (tone), 14 (tone), #,
indicates zones 1, 2, 13, and
14 are included in this group.
Enter the codes consecutively,
with no digit or character
between them. Use ALIAS
numbers, if optioned.
Otherwise, use Physical
zone/group numbers.
20 Set Zone Grouping to Page
This option allows you to select a group of zones to be paged at the
same time. The number of zone groups that can be formulated is eight;
the maximum number of zones per group is 56 zones.
The factory default is NONE (there are no default zone groups).
You will need to repeat this procedure for each zone group you wish to
set up.
1.
2.
3.
4.
5.
Dial 6 4 to select this option.
Hear a DOUBLE beep.
Enter the zone code, of the zone group to be defined (81 thru 88).
Hear a DOUBLE beep.
Enter zone codes of each zone to be included in the group.
Hear a Confirmation Tone for each zone, then dial tone
Press
# to end the string of zones.
Hear TRIPLE beeps.
To verify the zone group assignment, dial 6 5 and repeat steps 2
and 3 above.
Output Zone/Group Configurations
These options apply to zones or groups already configured as outputs
(see Step 17, “Type of Zone,”). All these parameters can be individually
optioned per zone. For a summary of these options, see the
Programming Quick Reference Chart at the end of this section.
Continued on next page...
