3.
4.
Press
0
to designate the zone as OUTPUT
Press
1
to designate it as INPUT #1, or
Press
2
to designate it as INPUT #2
Hear TRIPLE beeps.
To verify the zone type assignment, dial
6 3
and repeat steps 2
and 3 above.
18
Set Input Priority Arrangement
The input priorities are pre-set at the factory. You may only assign a
priority level to inputs such as doorbell or security alarm, by assigning
them to Input #1 or Input #2, which differ in priority.
NOTE: These priorities
cannot be rearranged.
Also, if you select more than
one zone to be inputs of the
same level (Input 1, for
example), such inputs will be
handled on a first in, first
served basis. See Type of
Zone option, under Zone /
Group Configurations
programming, later in this
section.
The default setting is:
1 – Attendant Access
2 – Input #1
3 – Telephone Access
4 – Input #2
5 – Night Bell
Music (always lowest priority)
19
Set Zone or Group Zone to Remote Monitor
This option selects a zone or group zone for computer monitoring,
(logging of paging activity), or for visual message display. The default
setting is off (Refer to Step 10).
1.
2.
3.
4.
Dial
6 6
to select this option.
Hear a DOUBLE beep.
Enter zone or group zone number.
Dial the code to activate this option:
0 to select OFF
1
to select ON.
Hear TRIPLE beeps.
To verify the status of this option, dial
6 7
and repeat step 2 above.
