Specifications

NOTE: Before doing this
option, you MUST do “Define
Length of ALIAS Numbers”
(see Step 3).
NOTE: If ALIAS numbers are
enabled, you MUST use them
for programming from now on.
When an ALIAS number for a
zone is changed, all the
previous zone options for that
zone will be transferred to the
new zone number.
NOTE: The INPUT #1 option
must only be assigned to
physical zones 1 through 8
(on the Controller).
16
Zone Map Option—Assigning ALlAS Numbers
Zone Map permits you to assign the dialing code, called the ALlAS zone
code, that you will dial to access a particular zone by telephone (i.e.,
instead of dialing 02 to make a page, you could dial 2202). The factory
default is NONE: no ALlAS numbers are pre-programmed. The zones
are identified by their 2-digit Physical Zone Codes (01 thru 56 and
groups 81-88) as the default condition.
Digit string length for an ALlAS code can be 3 or 4 digits, but all ALlAS
codes must have the same number of digits. (Refer to Step 3) The
✱
and # digits are not applicable digits for zone ALlAS numbers.
Refer to your own Zone Map and the Example Zone Map at the end of
this programming section.
1.
2.
3.
4.
Dial 6 0 to select this option.
Hear a DOUBLE beep.
Enter the 2-digit PHYSICAL zone/group code, of the zone to be
given an ALlAS number.
Hear a DOUBLE beep.
Enter the ALlAS zone/group number you have chosen.
Hear TRIPLE beeps.
To verify the assignment of an ALlAS to a selected zone or group,
dial 6 1 and repeat steps 2 and 3 above.
17
Type of Zone: Input or Output
The choices here are INPUT #1, INPUT #2, and OUTPUT. Be sure the
manually selectable Zone Option switch on the rear of the Controller or
Zone Expansion Unit is set to match the type of zone selected (input or
output). Input #1 would be used for an emergency alert, say a
connection to your alarm system. Input #2 would be a lower priority, say
a doorbell input.
The factory default is OUTPUT (i.e., all zones are output type, by default).
1.
Dial 6 2 to select this option.
Hear a DOUBLE beep.
2.
Enter the number of the zone or zone group to be optioned. Use
ALlAS numbers, if optioned. Otherwise, use Physical zone/group
numbers.
Hear a DOUBLE beep.
Continued on next page...
37
