Specifications

15
Inhibit Dial Tone Detect
Supervision of the Station/Centrex Access mode is accomplished in 3
ways, by monitoring the loop current and the audio signal (including dial
tone), and a forced disconnect timer. This option (only applicable in the
station access mode) enables you to defeat the dial tone detect function
in order to send a tone via the Telephone Interface to the output.
1.
2.
3.
Dial 2 4 to select this option
Hear a DOUBLE beep.
Dial 0 to turn Enable, or 1 to turn Inhibit
Hear TRIPLE beeps.
To verify the condition (OFF/ON) of the Dial Tone Detect option, dial
2 5 and repeat step 2 above.
General Zone and Zone Group Configurations
General Zone and Zone Group Configurations are options that apply to
selected zones or groups, not to the entire system. The steps following
“Copy Command,” describe each option.
COPY Command
The COPY command can be used to copy the configuration of a zone
that has already been optioned, to one or more additional zones. This
saves re-entering the same parameters over again, to duplicate the
parameters of an existing zone.
1.
2.
3.
4.
Dial 1 2 to activate COPY command.
Hear a DOUBLE beep tone.
Enter the zone number that you wish to copy from (i.e., 01).
Hear DOUBLE beep tone.
Enter the zone number of the beginning of the range of zones you
wish to copy to.
Hear a DOUBLE beep tone.
Enter the zone number of the END of the zone range to be copied to.
Hear a TRIPLE beep tone.
NOTE: Program the Controller
For example, to copy the parameters of zone 01 to all other zones, the
using the physical zone
range zone 02 to 56 would be entered in this step and the next. To copy
number.
to a single zone (for example, 02) enter that zone number as both the
beginning and the end of the range (02 to 02). In this step, enter only
the beginning zone of the zone range.
36
