Specifications

NOTE: Once the option has
been configured, you should
place the Controller Telephone
Mode switch to the Ground
Start position. Connect the
telephone interface to a Loop
Start trunk on the host system
using a standard two-conductor
(not four-conductor) RJ-11
cable.
NOTE: The Ground Start and
Station Access modes are not
available when the Controller is
configured for Supervised
Trunk mode. Supervised
Trunk mode must be turned off
to re-enable these access
modes.
13
Set Supervised Trunk Mode
If the host telephone system is not a Merlin Legend this feature does not
apply. Proceed to Step 14.
The Supervised Trunk access mode provides both VOX Disconnect and
Forced Disconnect timeouts. When the Controller detects that the it has
been off hook for two minutes, it opens the trunk circuit for one second,
ending the call. Also, if no voice activity is detected for the period
specified by the VOX Disconnect programming option (normally 30
seconds), or if the telephone is overridden by a higher priority activity
(i.e., attendant access), the call is disconnected.
1.
2.
3.
Dial 5 6 to select this option
Hear a DOUBLE beep.
Press 0 to turn OFF, or 1 to turn ON
Hear TRIPLE beeps.
To verify the condition (ON/OFF) of the Supervised Trunk mode,
dial
5 7 and repeat step 2 above.
14
Specify Zone Microphone
This option allows you to specify that a zone microphone is attached to
the Attendant Access interface. When the Zone Microphone option is
enabled (ON), the controller will wait for a zone to be selected from the
microphone keypad before it makes a page. When disabled (OFF), the
controller reverts to its normal (All Call) operation.
1.
2.
3.
Dial 5 8 to select this option
Hear a DOUBLE beep.
Dial 0 to turn OFF, or 1 to turn ON
Hear TRIPLE beeps.
To verify the condition (OFF/ON) of the Zone Microphone option,
dial
5 9 and repeat step 2 above.
