MERLIN LEGEND Planning
MERLIN LEGEND Form 8b:
Label Form—Stations and Calling
Groups
Use MERLIN LEGEND Form 8b to identify the labels you will see on display
phones. You need to identify the Calling Groups you have selected and the
MERLIN MAIL extensions. This example shows labels selected for the MERLIN
MAIL Calling Group and the four MERLIN MAIL ports. Fill in the appropriate
information for each Calling Group and the MERLIN MAIL ports:
MERLIN MAIL Calling Group
➀
Ext. No.
Write the MERLIN MAIL (Integrated VMI) Calling Group number here. This
number is from MERLIN LEGEND Form 6e. You may want to use the 3-
digit factory-set extension number instead, as shown in the example (also
from Form 6e).
➁
Label
Write MERMAIL here. Whenever the MERLIN MAIL system calls a sub-
scriber who has a display phone, this is the name that appears on the
display.
MERLIN MAIL Ports
➀
➁
Ext. No.
Write the extension numbers of the MERLIN MAIL ports. These numbers
are from MERLIN LEGEND Form 6e.
Label
Write MERMAIL here for each corresponding extension.
MERLIN LEGEND Form 8b
2-23
