User`s manual
Table Of Contents
- Contents
- Introduction
- Your ISDN 8510T Voice Terminal
- Feature Descriptions
- Voice Features
- Features Accessed with the Display and Softkeys
- ENTERING AND EXITING SOFTKEY MODE (USING THE MENU AND THE EXIT BUTTONS)
- THE VOICE TERMINAL SELF-TEST FEATURE bbbbbbb
- USING THE NEXT, THE PREV, AND THE DIR BUTTONS
- RESPONDING TO ´QUIT´ AND ´DONE´
- A SOFTKEY DISPLAY SCREEN FLOWCHART
- SETTING THE CLOCK
- SETTING THE SPEAKERPHONE
- ADDING, EDITING, AND DELETING A NUMBER AND NAME IN THE DIRECTORY
- VIEWING A DIRECTORY ENTRY (AND PLACING A CALL)
- USING THE DIR BUTTON TO PLACE A CALL
- USING THE CALL LOG
- LOCKING AND UNLOCKING THE DIRECTORY, CALL LOG, AND ALL SOFTKEYS
- CHANGING OR REMOVING YOUR PASSWORD
- SELF-TEST
- CHOOSING THE CONTRAST LEVEL FOR THE DISPLAY
- SELECTING A PERSONALIZED RING
- SETTING THE RATE AT WHICH YOU VIEW THE DISPLAY MESSAGES
- TURNING ON OR OFF SOFTKEY INFORMATION TONES
- SETTING THE NUMBER OF NAMES ON THE DIRECTORY PAGE
- Tones and Their Meanings
- Labeling and Installing the Designation Card and the Telephone Number Card
- Installation
- Technical Description
- Index
The display shows:
ENTER PHONE #:_
Pause Quit
5 Enter the telephone number you want to be added to the Directory.
(You can enter up to 24 digits. A pause counts as 1 digit.)
NOTE: To place a 1.5 second pause between an access code, such
as "9," and the telephone number, press the softkey below Pause. A
pause will be inserted into the Directory entry, and a comma will
appear on the display.
After you have entered at least one digit, you will see the
following display:
ENTER PHONE #:9_
Pause Backspace Done
IMPORTANT: Hyphens, dashes and/or spaces are NOT necessary
between digits. (For example, in the Directory, the number,
555-1234, is entered as "5551234," without the intervening hyphen.)
NOTE: After you have entered 10 digits, including any pauses, the
words, "Enter Phone #:" begin to move off the display screen one
letter at a time in order to accommodate the remainder of the
telephone number.
When you are finished entering the phone number, press the softkey
below Done .
The display shows:
ENTER 5-CHAR NAME:_
Quit
28
