The 8400B Plus Data Module
Issue 11 December 1999
21-29
You can check the current value stored in all S-registers with the &V command. To
look at the contents of just one register, use the command Smm? where “mm” is
the number of the S-register. The data module will return 3-digits, representing the
decimal value of the specified S-register.
To change the value in any one S-register directly, use the command Smm=nnn
where “mm” is the number of the S-register and “nnn” is the number you wish to
place in the register.
For a full description of all 28 S-registers, see Appendix C in the 8400B Plus Data
Module User’s Guide, 555-020-708.
Notes for Use with PC Packages
Like the 7400B Plus, the 8400B Plus is able to use the following PC
communication packages:
■ CARBON COPY Plus V5.1
■ Crosstalk
XVI V3.71
■ Crosstalk Mk.4 V1.1
■ Hot Line V2.2 (voice dialing packages)
■ HyperACCESS
V3.32
■ MicroPhone V1.5 (MacIntosh package)
■ PC TOOLS Deluxe V6 (voice dialing packages)
■ Procomm Plus
V1.1B
■ Relay Gold
V3.0
■ SideKick V1.5 and SideKick Plus
(voice dialing packages)
■ Smartcom
II V2.2
■ Smartcom II V3.1
■ Smartcom III V1.1
■ Smarterm 240 V3.0a
■ Terra Nova
V1.1.1
■ White Knight V11 (MacIntosh package)
