Data Modules
21-14 Issue 11 December 1999
7400B Data Module PECs
The 7400B and 7400B Plus data modules can be ordered using the following
PECs:
■ 7400B Plus Data Module
PEC: 2172-101
Comcode: 106545841
NOTE:
The 7400B Plus data module comes with a stand-alone power
supply.
Additional Documents
The following documents contain additional information relating to the 7400B and
7400B Plus data modules:
■ 7400B Data Module User’s Guide, 555-020-707
■ 7400B Plus Data Module User’s Guide, 555-020-710
■ DEFINITY Communications System Generic 1 and System 75 R1V2
Through R1V3 7400B Data Module Application Notes, 555-209-017
■ 7400B Data Module PC Applications Guide, 555-035-203
