The MDC 9000 Cordless Telephone
Issue 11 December 1999
18-9
Figure 18-4 for button numbering on the MDC 9000 set when it is connected to a
System 85 or a DEFINITY Generic 2.
NOTE:
On System 75, the DEFINITY Generic 1 and Generic 3, or a DEFINITY
ECS, button numbering begins with “1,” the button on the upper right of the
display. On System 85 and the DEFINITY Generic 2, button numbering
starts with “3.”
Figure 18-3. Button Numbering for a MDC 9000 Connected to System 75,
a DEFINITY Generic 1 or Generic 3, or a DEFINITY ECS
Figure 18-4. Button Numbering for a MDC 9000 Connected to
System 85 or a DEFINITY Generic 2
ON
RANGE
P STAT
MSG
BATT
321
5 4 DROP
ON
RANGE
P STAT
MSG
BATT
543
7 6 DROP
