The 7400 Series Voice Terminals
11-60 Issue 11 December 1999
7406 Plus Equipment PECs and Comcodes
The 7406 Plus voice terminal and components can be ordered with the following
PECs and Comcodes:
■ Basic 7406D07A Voice Terminal with display with built-in
speakerphone
PEC: 3182-PLS (Black=COL09; Misty Cream=COL22)
Comcode: Black=106202443; Misty Cream=106202450
■ Basic 7406D08A Voice Terminal without display with built-in
speakerphone
PEC: 3183-PLS (Black=COL09; Misty Cream=COL22)
Comcode: Black=106202468; Misty Cream=106202476
■ Handset
PEC: 3152-006
Comcode: Black=105519086; Misty Cream=105520787
■ Handset cord (9 feet)
Comcode: Black=105635429; Misty Cream=105635437
■ Handset cord (12 feet)
PEC: 2725-01L (Black=COL09; Misty Cream=COL22)
Comcode: Black=102401445; Misty Cream=104211339
■ Line cord (7 feet, silver)
Comcode: 103786778
■ Line cord (14 feet, silver)
PEC: 2725-07N COL18
Comcode: 103786802
■ Line cord (25 feet, silver)
PEC: 2725-07S COL18
Comcode: 103786828
■ Graphic panel
Comcode: Black=846517134; Misty Cream=846517142
■ Button designation cards
PEC: 31827 (Package of 25 cards)
Single card Comcode: 846519056
25 cards Comcode: 846518124
200 cards Comcode: 846518132
500 cards Comcode: 846518140
■ Display bezel (for display-equipped sets)
Comcode: Black=846534055; Misty Cream=846534063
■ Blank bezel (for sets without display)
Comcode: Black=846534097; Misty Cream=846534105
■ Wall mount kit
Comcode: 106304298
