The 7400 Series Voice Terminals
11-12 Issue 11 December 1999
FCC Registration
These voice terminals are FCC-registered along with the switch (as a system), but
do not have a separate FCC registration label.
UL and CSA Approval
These voice terminals have been tested and have met the Underwriters
Laboratories (UL) Standards UL 1459 and have also met the Canadian Standards
Association (CSA) Standards CSA-C22.2 No.225-M90.
Hearing Aid Compatible
These voice terminals are compatible with the inductively coupled hearing aids
prescribed by the FCC.
7401D Equipment PECs and Comcodes
The 7401D (7401D01A) voice terminals and components can be ordered with
these Price Element Codes (PECs) and Comcodes:
■ Basic 7401D Voice Terminal
PEC: 3184-CDT (Black=COL09; Misty Cream=COL22)
Comcode: Black=105353056; Misty Cream=105269153
■ Handset
Comcode: Black=105157291; Misty Cream=105158885
■ Handset cord (9 feet)
Comcode: Black=105635429; Misty Cream=105635437
■ Handset cord (12 feet)
PEC: 2725-01L (Black=COL09; Misty Cream=COL22)
Comcode: Black=102401445; Misty Cream=104211339
■ Line cord (7 feet, silver)
Comcode: 105304646
■ Line cord (14 feet, silver)
PEC: 2725-07N (COL18)
Comcode: 103786802
■ Line cord (25 feet, silver)
PEC: 2725-07S (COL18)
Comcode: 103786828
■ Faceplate and tab
Comcode: Black=846209161; Misty Cream=846209179
