The 7300 Series Voice Terminals
10-6 Issue 11 December 1999
Hearing Aid Compatible
The 7303S voice terminal is compatible with the inductively coupled hearing aids
prescribed by the FCC.
7303S Equipment PECs
The 7303S voice terminal and optional components were ordered with the
following PECs:
■ Basic 7303S Voice Terminal — 3176-16S/CLR
■ Handset cord (12 feet — 2725-01L COL09
■ Line cord (14 feet, silver) — 2725-07N COL18
■ Line cord (25 feet, silver) — 2725-07S COL18
Adjuncts
One of the following adjuncts can be used with this voice terminal:
■ S102A Speakerphone
■ S202A Speakerphone
■ 502A Headset Adapter and a standard headset
Additional Documents
The following documents contain additional information relating to the 7303S
voice terminal:
■ DEFINITY Generic 2, System 85 7303S Voice Terminal User’s Guide,
555-103-707
■ DEFINITY Generic 1, System 75 7303S Voice Terminal User’s Guide,
555-200-706
■ DEFINITY Generic 1 and Generic 2, System 75, and System 85 Terminals
and Adjuncts Installation and Test, 555-015-104
