Specifications

The 6416D+ and 6416D+M Telephones
Issue 11 December 1999
7-33
Ringing
The 6416D+ and 6416D+M telephones have electronic tone ringing with eight
possible ringing patterns which you can select by pressing the CONF button while
on-hook. The loudness of the tone ringer can be controlled by the VOLUME
“arrow” button. (The user must NOT be on a speakerphone call. If the user is
using the speakerphone, the VOLUME “arrow” button controls the volume of the
speakerphone.)
Mounting Options
The 6416D+ and 6416D+M telephones come equipped with a nonadjustable desk
stand. The user of the 6416D+ can reverse the stand and then mount the
telephone on the wall.
However, if there is a module connected in the Modular 6416D+M telephone’s
desktop stand, the telephone can ONLY be desk mounted: it CANNOT be
wall-mounted.
Color Options
The 6416D+ and 6416D+M telephones are available in gray and in white.
Wiring Information
The 6416D+ and 6416D+M telephones work in a 2-wire DCP configuration ONLY.
The table below describes the pins on a 6400-Series telephone LINE jack.
Notes on 6400 Series 2-Wire Installation and Wiring:
ALL wiring between the PBX and the telephone wall jack MUST consist of
twisted-pairs. The line cord must be either a D8W, which consists of 4
twisted-pairs, or a D2R which is a 2-conductor non-twisted pair cord. Only these
cord types have been approved by Lucent Technologies. For optimum
performance, the line cord length should not extend beyond that originally
supplied with the telephone.
Table 7-7. The Pins on a 6400-Series Telephone LINE Jack
Line Interface
Pin Pair Name Description
4 1 U-T 2-Wire (Tip)
5 1 U-R 2-Wire (Ring)
7 4 P1- Adjunct Power -48V
8 4 P2+ Adjunct Power Common
