E17166 30( 3BQUVSF 5SJ CBOE (BNJOH 3PVUFS
ROG GT-AXE11000 Wireless Router 8 * wireless antennas AC adapter Network cable (RJ-45) English Package contents Quick Start Guide NOTE: If any of the items is damaged or missing, contact your retailer. A quick look at your ROG router 2 4 3 5 7 8 9 1 10 1. 2. 3. 4. 5. 6. 7. 6 Wi-Fi On/Off button WPS button Boost Key Power (DCIN) port Power button Reset Button LAN ports 8. 9. 10. 11. 12. 13. 14. 11 12 13 14 2.5G Gaming port WAN (Internet) port WAN (Internet) LED LAN LED 2.
Specifications: English DC Power adapter DC Output: +19V with max 3.42A current DC Output: +19.5V with max 3.33A current Operating Temperature 0~40oC Storage 0~70oC Operating Humidity 50~90% Storage 20~90% Preparing your modem 1. Unplug the power cable/DSL modem. If it has a battery backup, remove the battery. NOTE: If you are using DSL for Internet, you will need your username/password from your Internet Service Provider (ISP) to properly configure the router. 2.
Setting up your ROG router English You can set up your ROG router via wired or wireless connection. A. Wired connection 1. Plug your router into a power outlet and power it on. Connect the network cable from your computer to a LAN port on your router. Modem LINE LAN RESET PWR Wall Power Outlet Power 1 2 LAN Laptop 3 WAN 2. The web GUI launches automatically when you open a web browser. If it does not auto-launch, enter http://router.asus.com 3.
2. Connect to the network name(SSID) shown on the product label on the back side of the router. For better network security, change to a unique SSID and assign a password. English ASUS router 2.4G Wi-Fi Name (SSID): ASUS_XX_2G 5G Wi-Fi Name (SSID): * ASUS_XX_5G XX refers to the last two digits of 2.4GHz MAC address. You can find it on the label on the back of your ROG router. 3. Once connected, the web GUI launches automatically when you open a web browser.
Remembering your wireless router settings Remember your wireless settings as you complete the router setup. Router Name: Password: 2.4GHz network SSID: Password: 5GHz network SSID: Password: English • FAQ 1. Where can I find more information about the wireless router? • Technical support site: https://www.asus.
ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling information in different regions.
Prohibition of Co-location This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance.
English CE statement Simplified EU Declaration of Conformity ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Full text of EU declaration of conformity is available at https://www.asus.com/ca-en/Networking/ROG-Rapture-GT-AXE11000/HelpDesk_Declaration/.
