WebSTAR DPR2320 and EPR2320 Gateway Cable Modems User’s Guide
32
How Do I Configure the Gateway Cable Modems?
To configure your gateway cable modem, you must access the WebWizard configuration pages. This section
provides detailed instructions and procedures for configuring your gateway cable modem to operate correctly and
presents an example of each WebWizard page. Use the WebWizard pages to customize your gateway cable
modem to your needs rather than using the default settings.
The WebWizard pages and the examples shown in this section are for illustration purposes only. Your pages will
differ from the pages shown here.
If you are not familiar with the network configuration procedures detailed in this section, contact your cable
service provider before you attempt to change any of the gateway cable modem default settings.
Configuring the Gateway Cable Modem
You must access the WebWizard in order to configure the gateway cable modem.
To gain access to the WebWizard, use the Web browser on the PC attached to
the cable modem. Type the following IP address and then select Go:
http://192.168.0.1
The Web browser accesses the WebWizard and displays the default About Your
Modem page. This page displays information about the gateway cable modem.
About Your Modem Page Example
The following illustration is an example of the About Your Modem page.
