5-32 Chapter 5: BIOS setup
5.4.9 Trusted Computing
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Conguration
TPM SUPPORT [Enabled]
Current Status Information
No Security Device Found
TPM Support [Enabled]
Allows you to enable or disable the TPM support.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Enable/Disable USB 2.0 (EHCI)
Support.
EHCI Controller 1 [Enabled]
EHCI Controller 2 [Enabled]
Rear USB #1 [Enabled]
Rear USB #2 [Enabled]
Onboard USB #3 [Enabled]
Onboard USB #4 [Enabled]
Onboard USB #5 [Enabled]
Onboard USB #6 [Enabled]
Onboard USB #10 [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
USBPortsConguration
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
EHCI Controller 1/2 [Enabled]
Allows to enable or disable USB 2.0 (EHCI) Support. If we disable the EHCI
Controller in BIOS > South Bridge > USB conguration, the USB device will all
disable in OS.
Conguration options: [Disabled] [Enabled]
Rear USB #1 and #2 [Enabled]
Allows to enable or disable rear USB #1 and #2.
Conguration options: [Disabled] [Enabled]
Onboard USB #3/#4/#5/#6/#10 [Enabled]
Allows to enable or disable Onboard USB #3 / #4 / #5 / #6 / #10.
Conguration options: [Disabled] [Enabled]
