ASUS RS700-E7/RS4-C 5-21
The following item appears only when you set
ME SMBus Thermal Peporting
to [Enabled].
PCH Temp Read [Enabled]
Allows to enabled/disabled PCH Temperature Read.
Conguration options: [Disabled] [Enabled]
CPU Energy Read [Enabled]
Allows to enabled/disabled CPU Energy. Conguration options: [Disabled] [Enabled]
CPU Temp Read [Enabled]
Allows to enabled/disabled CPUTemperature Read.
Conguration options: [Disabled] [Enabled]
Alert Enable Lock [Disabled]
Allows to lock all alert enabled settings.Conguration options: [Disabled] [Enabled]
Enables or Disables BIOS ACPI
Auto Conguration.
Intel(R) VT-d [Disabled]
Intel(R) VT-d [Disabled]
Allows to enabled/disabled High Precision Event Timer.
Conguration options: [Enabled] [Disabled]
Intel(R)VTforDirectedI/OConguration
The following item appears only when you set
Alert Enable Lock
to [Enabled].
PCH Alert [Disabled]
Allows to enabled/disabled PCH Alert pin. Conguration options: [Disabled]
[Enabled]
DIMM Alert [Disabled]
Allows to enabled/disabled DIMM Alert pin.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set
Intel(R) VT-d
to [Enabled].
Interrupt Remapping [Enabled]
Allows to enable/disable VT-d Engine Interrupt Remapping support.
Conguration options: [Disabled] [Enabled]
Coherency Support [Disabled]
Allows to enable/disable VT-d Engine Coherency support.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
