5-20 Chapter 5: BIOS setup
SCU devices [Enabled]
Allows to enabled/disabled Patsburg SCU devices.
Conguration options: [Enabled] [Disabled]
Onboard SAS Oprom [Enabled]
Allows to enabled/disabled onboard SAS option rom if Launch Storage Oprom is
enabled. Conguration options: [Disabled] [Enabled]
Onboard SATA RAID Oprom [Enabled]
Allows to enabled/disabled onboard SATA RAID option rom if Launch Storage
Oprom is enabled. Conguration options: [Disabled] [Enabled]
HighPrecisionEventTimerConguration
High Precision Timer [Enabled]
Allows to enabled/disabled High Precision Event Timer.
Conguration options: [Disabled] [Enabled]
Thermal Management [Disabled]
Allows to enable/disable thermal management. If enabled will initilaize the PCH
Thermal susbsystem davice, D31:F6. Conguration options: [Disabled] [Enabled]
The following item appears only when you set
Thermal Management
to
[Enabled].
ME SMBus Thermal Peporting [Disabled]
Allows to enable/disable thermal ME SMBus thermal reporting.
Conguration options: [Disabled] [Enabled]
Mobile platforms support deep S4/S5 in DC only and desktop platforms support
deep S4/S5 in AC only.
SMBus Controller [Enabled]
Allows to enabled/disabled SMBus controller.
Conguration options: [Disabled] [Enabled]
SLP_S4 Assertion Stretch Enable [Enabled]
Allows to enabled/disabled SLP_S4# assertion stretch.
Conguration options: [Disabled] [Enabled]
SLP_S4 Assertion Stretch Enable [4-5 Seconds]
Select a minimum assertion width of the SLP_S4# signal.
Conguration options: [1-2 Seconds] [2-3 Seconds] [3-4 Seconds] [4-5 Seconds]
Deep Sx [Disabled]
Conguration options: [Disabled] [Enabled in S5 (Battery)] [Enabled in S5] [Enabled
in S4 and S5 (Battery)] [Enabled in S4 and S5]
