Support for PCH Compatibility
Revision ID(CRID)
functionality.
Name Patsburg
Stepping 05 (C0 Stepping)
SB Chipset Conguration
PCH Compatibility RID [Disabled]
SMBus Controller [Enabled]
SLP_S4 Assertion Stretch Enable [Enabled]
SLP_S4 Assertion Stretch Enable [4-5 Seconds]
Deep Sx [Disabled]
SCU devices [Enabled]
Onboard SAS Oprom [Enabled]
Onboard SATA RAID Oprom [Enabled]
High Precision Event Timer Conguration
High Precision Timer [Enabled]
Thermal Management [Disabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
PCHConguration
PCH Compatibility RID [Disabled]
Support for PCH compatibility.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
IOU2 - PCIe Port [x16]
Conguration options: [x4x4x4x4] [x4x4x8] [x8x4x4] [x8x8] [x16]
PORT 2A Link Speed [Gen2]
Select target link speed Gen1, Gen2 or Gen3.
Conguration options: [Gen1] [Gen2] [Gen3]
IOU3 - PCIe Port [x8x8]
Conguration options: [x4x4x4x4] [x4x4x8] [x8x4x4] [x8x8] [x16]
PORT 3A Link Speed [Gen2]
Select target link speed Gen1, Gen2 or Gen3.
Conguration options: [Gen1] [Gen2] [Gen3]
PORT 3C Link Speed [Gen2]
Select target link speed Gen1, Gen2 or Gen3.
Conguration options: [Gen1] [Gen2] [Gen3]
IOH1 PCIe port Bifurcation Control
This item appears only when you installed CPU2 on the motherboard.
