Chapter 2: Hardware setup2-10
Ranks
Per DIMM
and Data
Width
Memory Capacity Per DIMM
Speed (MT/s) and Voltage Validated by Slot Per Channel (SPC) and
DIMM Per Channel (DPC)
3 Slots Per Channel
1DPC 2DPC 3DPC
1.35V 1.5V 1.35V
1.5V 1.35V 1.5V
SRx8 1GB 2GB 4GB
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600
N/A
800,
1066
DRx8 2GB 4GB 8GB
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600
N/A
800,
1066
SRx4 2GB 4GB 8GB
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600
N/A
800,
1066
DRx4 4GB 8GB 16GB
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600
N/A
800,
1066
QRx4 8GB 16GB 32GB 800 1066 800 800 N/A N/A
QRx8 4GB 8GB 16GB 800 1066 800 800 N/A N/A
Intel Xeon E5-2600 Series Processor RDIMM Memory Support List
Ranks
Per DIMM
and Data
Width
Memory Capacity Per
DIMM
Speed (MT/s) and Voltage Validated by Slot
Per Channel (SPC) and DIMM Per Channel
(DPC)
3 Slots Per Channel
1DPC and 2DPC 3DPC
1.35V 1.5V
1.35V 1.5V
QRx4
(DDP)*
16GB 32GB 1066
1066,
1333
1066 1066
QRx8 (P)** 8GB 16GB 1066
1066,
1333
1066 1066
Intel Xeon E5-2600 Series Processor LRDIMM Memory Support List
* DDP-Dual Die Package DRAM stacking.
** P-Planer monolithic DRAM die.
