ASUS RS700-E7/RS4-C 5-47
5.8 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
CPU1 Temperature 54.0ºC/129.2ºF
CPU2 Temperature N/A
TR1 Temperature 35.0ºC/95.0ºF
TR2 Temperature 40.0ºC/104.0ºF
CPU FAN1 Speed 5378 RPM
CPU FAN2 Speed N/A
FRNT FAN1 Speed N/A
FRNT FAN2 Speed N/A
FRNT FAN3 Speed N/A
FRNT FAN4 Speed N/A
REAR FAN1 Speed N/A
REAR FAN2 Speed N/A
+VTT_CPU +1.026 V
VCORE1 +0.996 V
VCORE2 +0.996 V
+VDDQ_AB_CPU1 +1.510 V
+VDDQ_CD_CPU1 +1.526 V
+VDDQ_EF_CPU2 N/A
+VDDQ_GH_CPU2 N/A
+5VSB +4.921 V
+12V +11.592 V
+3.3V +3.276 V
CPU 1/2; TR1 1/2 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures. Select Ignore if you do not wish to display
the detected temperatures.
CPU FAN1/2 Speed; FRNT FAN1–4 Speed; REAR FAN1/2 Speed
[xxxx RPM] or [Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the eld shows
N/A
.
+VTT_CPU Voltage, VCORE1/2 Voltage, +VDDQ_AB_CPU1
Voltage, +VDDQ_CD_CPU1 Voltage, +VDDQ_EF_CPU2 Voltage,
+VDDQ_GH_CPU2 Voltage, +5VSB Voltage, +5V Voltage, +12V
Voltage, +3.3V Voltage, VBAT Voltage, +3.3VSB Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
Scroll down to display the following items:
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Server Mgmt Event Logs Boot Monitor Security Tool Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
VBAT +3.168 V
+3.3VSB +3.234 V
FAN Speed Control [Generic Node]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
